CAC50121LW is a 120W(P5dB) input pre-matched GaN power amplifier. It operates perfectly from 3 to 5GHz with 28 volts rail, offers a general purpose, broadband, high power and high efficiency wireless pulse or CW wideband communication application.

·3 – 5GHz
·Operating Drain Voltage: +28V
·15dB small signal Gain @5GHz
·13dB Gain @ 50dBm	5GHz
·50.5dBm CW Peak Power
·65% Drain Efficiency @peak power	5GHz
·NI360 2 Lead flange Ceramic package(MSL3	260℃ per JEDEC J-STD-020)
·ESD Level: HBM TBD ; CDM TBD
·ROHS compatible

Parameter Conditions Min Typ Max Unit

Frequency 5000 MHz

Output P5dB CW +50.0 dBm

Gain @ 50dBm CW 13 dB

Drain efficiency @Psat CW 65 %

• 3GPP 4G LTE/5G NR massive MIMO basestation
• Driver amplifier for micro-base and macro-base
• Stations
• Active antenna array
• Pico/Small Cell
• Test Instrumentation
• Industrial, scientific, and medical
• Wideband amplifiers
