CAC60101LW is a 110W(P3dB) internally input & output-matched GaN power amplifier. It operates perfectly from 4.6 to 6GHz with 28 volts rail, offers a general purpose, broadband, high power and high efficiency wireless pulse or CW communication application.

·4.6 – 6GHz
·Operating Drain Voltage: +28V
·11.5dB small signal Gain @5.3GHz
·10dB Gain @ 50dBm	5.3GHz
·51dBm CW Peak Power
·66% Drain Efficiency @51dBm	5.3GHz
·NI670 4 Lead flange Ceramic package(MSL3	260℃ per JEDEC J-STD-020)
·ESD Level: HBM TBD ; CDM TBD
·ROHS compatible

Parameter Conditions Min Typ Max Unit

Frequency 5300 MHz

Output P3dB CW +51 dBm

Gain @ small signal CW 12 dB

Drain efficiency @P3dB CW 66 %

• 3GPP 4G LTE/5G NR massive MIMO basestation
• Driver amplifier for micro-base and macro-base Stations
• Active antenna array
• Pico/Small Cell
• Test Instrumentation
• Industrial, scientific, and medical
• Wideband amplifiers
