CAC30203L is a 200W(P3dB) internally matched GaN power amplifier. It operates perfectly from DC to 3GHz with 28 volts rail, offers a general purpose, broadband, high power and high efficiency wireless pulse or CW communication application.

·DC – 3GHz
·Operating Drain Voltage: +28V
·18dB small signal Gain @1.3GHz
·16dB Gain @ 53dBm	1.3GHz
·53.5dBm CW Peak Power
·72.5% Drain Efficiency @53.5dBm	1.3GHz
·NI780 4 Lead flange Ceramic package(MSL3	260℃ per JEDEC J-STD-020)
·ESD Level: HBM TBD ; CDM TBD
·ROHS compatible

Parameter Conditions Min Typ Max Unit

Frequency 1300 MHz

Output P3dB CW +53 dBm

Gain @ P3dB CW 16 dB

Drain efficiency @P3dB CW 71 %

•  3GPP 4G LTE/5G NR massive MIMO basestation
•  Driver amplifier for micro-base and macro-base Stations
•  Active antenna array
•  Pico/Small Cell
• Test Instrumentation
• Industrial, scientific, and medical
• Wideband amplifiers
